Description

The XL6009 Boost Converter is a high-efficiency DC-DC step-up (boost) module capable of converting input voltages from 5V–32V to a higher adjustable output voltage up to 35V. It provides up to 4A output current (peak) with overcurrent, over-temperature, and short-circuit protection. Compact and easy to use, this module is ideal for Arduino, ESP32, Raspberry Pi, and general electronics projects that require a higher DC voltage from a lower supply.

Key Features

• Adjustable output voltage: up to 35V

• Input voltage range: 5V–32V DC

• Maximum output current: 4A (peak)

• High efficiency: up to 94%

• Overcurrent, over-temperature, and short-circuit protection

• Compact design with potentiometer for easy voltage adjustment

• Compatible with Arduino, ESP32, Raspberry Pi, and microcontrollers

Variants

• XL6009 Standard Boost Converter Module

• XL6009 with pre-soldered wires for easier prototyping

Specifications

Applications

• Boosting battery voltage for Arduino, ESP32, and Raspberry Pi projects

• Powering sensors and modules requiring higher voltage

• DIY electronics and IoT projects

• Robotics and small automation circuits

• LED strips and other low-power DC devices

Compatible Boards / Circuits

• Arduino Uno, Mega, Nano

• ESP32 / ESP8266

• Raspberry Pi (for peripherals)

• Any microcontroller or DC project needing higher voltage
